Soviet Era Slide Rules

CCCP Счётная линейка (USSR Counting Ruler)
Logarifmicheskaya Linyeika (Logarithmic Ruler)

KEEP ISRM FREE!
Donations are
tax deductable

KLPZ

TU

LFAI

Ramenskoye

Ramenskoye Fabreka

Tehnolemn

Leningrad

(Makes KL-1's)

OAO Kalibr Moscow

UGK

Note: On almost every one of these slide rules you will see something like: ГOST5151-57. ГOST translates into the letters GOST which is an abbreviation of ГOCYДPCTBEHHЦЙ or GOVERNMENT which we abbreviate as GOVT. ГOST5161-49, ГOST5161-57, and ГOST5161-72 were the Soviet Standards (like the United States MIL-STD or ANSI standards) which dictated identical design of the scales for all factory locations. The dash numbers -49, -57 and -72 were the years that the standard was revised. The year (r.) built, noted as 1971r., will always be greater than the GOST standard on the slide rule. Another Soviet era standard that appeared in 1972 on some injection molded plastic stock slide rules is: ТУ(TU) 25.01.610-72. Note: the terms LSLD and LSLO mean the type of slide rule construction, LSLD=Duplex and LSLO=Open (or simplex). For reference, Ramenskoye was the centre of the Russian instrument making, in the same place experimental test airdrome "Ramenskoye" (space, military aircraft) was located.

Refer to Russian alphabet at bottom of page
Instruction Sheet (Russian) 2.24Mb

OAO Kalibr-Moscow Moscow, Russia


REF OAO Kalibr Moscow Circular Slide Rule Calculator	OAO Kalibr Moscow Circular Slide Rule Calculator Made in USSR by OAO Kalibr-Moscow Front Scale (with logo) K, A, C ( D, CI ) Back Scale: T, ST, S ( C, L ) Photo Contributed By Dushan Grujich Collection, Australia

Factory No. 10, Kiev, Ukraine


Soviet-Factory No.10 1952 S366	Soviet-Factory No.10 1952 Made in USSR/CCCP- FKA No.10 - Factory Number 10, Kiev, Ukraine Front Scale 25cm // K, A [ B, CI, C ] D, L \|\| 25cm Back Slide: [ S, S&T, T ]
Soviet-Factory No.10 1957 S379	Soviet-Factory No.10 1952 Made in USSR/CCCP- FKA No.10 - Factory Number 10, Kiev, Ukraine Front Scale 25cm // K, A [ B, CI, C ] D, L \|\| 25cm Back Slide: [ S, S&T, T ]

KLPZ - SCHETNII INSTRUMENTI
KIEV ruler appliances plant, Ukraine


P063 Soviet-KLPZ 5161-57 Pocket 1969	Soviet-KLPZ 5161-57 Pocket 1969 Made in USSR/CCCP- KLPZ factory Front Scale K, A [ B, CI, C ] D, L Back Slide: [ Sin, S&T, Tg ]
P215 Soviet-KLPZ 5161-57 Pocket 1969	Soviet-KLPZ 5161-57 Pocket 1969 Made in USSR/CCCP- KLPZ factory Front Scale K, A [ B, CI, C ] D, L Back Slide: [ Sin, S&T, Tg ]
P193 Soviet-KLPZ 5161-57 Pocket 1970	Soviet-KLPZ 5161-57 Pocket 1969 Made in USSR/CCCP- KLPZ factory Front Scale K, A [ B, CI, C ] D, L Back Slide: [ Sin, S&T, Tg ]
P189 Soviet-KLPZ 5161-57 Pocket 1971	Soviet-KLPZ 5161-57 Pocket 1971 Made in USSR/CCCP- KLPZ factory Front Scale K, A [ B, CI, C ] D, L Back Slide: [ Sin, S&T, Tg ]
P064 Soviet-KLPZ 5161-57 Pocket 1972	Soviet-KLPZ 5161-57 Pocket 1972 Made in USSR/CCCP- KLPZ factory Front Scale K, A [ B, CI, C ] D, L Back Slide: [ Sin, S&T, Tg ]
S193 Soviet-KLPZ 5161-57 1961	Soviet-KLPZ 5161-57 1961 Made in USSR/CCCP- KLPV(Z?) factory Front Scale 25cm // K, A [ B, CI, C ] D, L \|\| 2:1 50cm Back Scale: [ Sin, S&T, Tg ] Back: Conversion Tables
S160 Soviet-KLPZ 5161-57 1964	Soviet KLPZ 5161-57 1964 Made in USSR/CCCP- KLPZ factory Front Scale 25cm // K, A [ B, CI, C ] D, L \|\| 2:1 50cm Back Scale: [ Sin, S&T, Tg ] Back: Conversion Tables
S083 Soviet KLPZ 5161-57 1965	Soviet KLPZ 5161-57 1965 Made in USSR/CCCP- KLPZ factory Front Scale 25cm // K, A [ B, CI, C ] D, L \|\| 2:1 50cm Back Scale: [ Sin, S&T, Tg ] Back : Conversion Tables
S346 Soviet-KLPZ 5161-57 1966	Soviet-KLPZ 5161-57 1966 Made in USSR/CCCP- KLPZ factory Front Scale 25cm // K, A [ B, CI, C ] D, L \|\| 2:1 50cm Back Scale: [ Sin, S&T, Tg ] Back: Conversion Tables
S422 Soviet KLPZ USL-12 M-1 1966 Dual Slides	Soviet KLPZ USL-12 M-1 1966 Dual Slides Made in USSR/CCCP- KLPZ factory Front Scale (Standard 5161-57) 25cm // K, A [ B, CI, C ] D, L \|\| 2:1 50cm Back Scale (Standard): [ Sin, S&T, Tg ] Front Scale(M-1) 25cm // K, A [ t, dv, S ] D, L \|\| 2:1 50cm Back Scale (M-1): [ t1, K, t 2, S1, S2 ] Back: Conversion Tables Insert: Instructions/Tables Original Owner initials: KAH
S084 Soviet KLPZ 5161-57 1971	Soviet KLPZ 5161-57 1971 Made in USSR/CCCP- KLPZ factory Front Scale 25cm // LL1, A [ B, CI, C ] D, LL3 \|\| LL2 Back Scale: [ Sin, S&T, Tg ] Back: Conversion Tables
S236 Soviet 5161-57 KLPZ 1971	Soviet KLPZ 5161-57 1971 Metal_Cursor Made in USSR/CCCP- KLPZ factory Front Scale 25cm // LL1, A [ B, CI, C ] D, LL3 \|\| LL2 Back Scale: [ Sin, S&T, Tg ] Back: Conversion Tables
S235 Soviet 5161-57 KLPZ 1971	Soviet KLPZ 5161-57 1971 Plastic Cursor Made in USSR/CCCP- KLPZ factory Front Scale 25cm // LL1, A [ B, CI, C ] D, LL3 \|\| LL2 Back Scale: [ Sin, S&T, Tg ] Back: Conversion Tables
S439 Soviet-KLPZ 250-11 5161-72 1975	Soviet-KLPZ 250-11 5161-72 1975 Plastic Cursor Made in USSR/CCCP- KLPZ factory, LSLO layout Front Scale 25cm // K, A [ B, CI, C ] D, LL3 \|\| LL2 Back Scale: [ Sin, S&T, Tg ] Back: Conversion Tables
S421 Soviet KLPZ - LSLO 250-11 5161-57 1976	Soviet KLPZ - LSLO 250-11 5161-57 1976 Made in USSR/CCCP- KLPZ factory, LSLO layout Front Scale 25cm // K, A [ B, CI, C ] D, LL3 \|\| LL2 Back Scale: [ Sin, S&T, Tg ] Back: Conversion Tables
S085 Soviet KLPZ 250-14 5161-57 1976	Soviet KLPZ 250-14 5161-57 1976 Made in USSR/CCCP- KLPZ factory Front Scale T₁, K, A [ B, CIF, CI, C ] D, ST, Ssin, Scos Back Scale LL₃, LL2, LL₁, L [Conversion Tables] Instructions
S372 Soviet-KLPZ Hydro	Soviet-KLPZ Hydro - for Civil Engineer Made in USSR/CCCP- KLPZ factory Front Scale:TBD Back Scale: TBD Instructions

Lenningrad Factory


S378 Soviet Lenningrad 5161-57 1973	Soviet Lenningrad 5161-57 1973 - LSLD Duplex Made in USSR/CCCP- Leningrad Factory Front Scale K, A [ B, S, ST, T, C ] D, DI Back Scale: L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
S374 Soviet LSLD Lenningrad 5161-72 1976	Soviet LSLD Lenningrad 5161-72 1976 - LSLO Open Made in USSR/CCCP- Leningrad Factory Front Scale 25cm // K, A [ B, CI, C ] D, LL3 \|\| LL2 Back Slide: [ S, ST, T ]
S373 Soviet LSLD Lenningrad 5161-72 1977	Soviet LSLD Lenningrad 5161-72 1977 - LSLD Duplex Made in USSR/CCCP- Leningrad Factory Front Scale K, A [ B, S, ST, T, C ] D, DI Back Scale: L [ Instructions ] 25cm

LFAI

Otdel Mectnoi Promezhlennocti Lengoricpolkoma
Fabrika Schetnex Priborob, Leningrad
Department of Local Industry of Leningrad Municipal Executive Committee
Plant of computational instruments, Leningrad.

Soviet LFAI 20 inch Rietz 5161-57 1964
ISRM 19.06.02.01

Soviet LFAI 20 inch Rietz 5161-57 1964 Made in USSR/CCCP- LFAI factory
Stock is 22 inches long
Front Scale
50cm // K, A [ B, CI, C ] D, L || 50cm
Back Slide: [ S, ST, T ]
Note: Received from St. Petersburg, Russia. The lens was missing and had to be fabricated.

P024 Soviet LFAI Pocket 5161-49 1952

Soviet LFAI Pocket 5161-49 1952
Made in USSR/CCCP- LFAI factory
Front Scale
K, A [ B, CI, C ] D, L
Back Slide: [ S, ST, T ]

P026 Soviet LFAI Pocket 5161-72 1977

Soviet LFAI Pocket 5161-72 1977
Made in USSR/CCCP- LFAI factory
Front Scale
K, A [ B, CI, C ] D, L
Back Slide: [ S, ST, T ]

S391 Soviet LFAI F-KA 5161-57 1964

Soviet CCCP 5161-57 1964
Made in USSR/CCCP- LFAI factory
Front Scale
25cm // K, A [ B, CI, C ] D, L || 1:25
Back Scale: Conversion Tables

S387 Soviet LFAI F-KA 5161-57 1965

Soviet CCCP 5161-57 1965
Made in USSR/CCCP- LFAI factory
Front Scale
25cm // K, A [ B, CI, C ] D, L || 1:25
Back Scale: Conversion Tables

S430 Soviet LFAI 5161-57 1967

Soviet LFAI 5161-57 1967
Made in USSR/CCCP- LFAI factory
Front Scale
25cm // K, A [ B, CI, C ] D, LLL3 || LL2
Back Scale: Conversion Tables

S419 Soviet LFAI 5161-57 1968

Soviet LFAI 5161-57 1968
Made in USSR/CCCP- LFAI factory
Front Scale
25cm // LL1, A [ B, CI, C ] D, LL3 || LL2
Back Scale: Conversion Tables

S229 Soviet LFAI 5161-57 1970

Soviet CCCP 5161-57 1970
Made in USSR/CCCP- LFAI factory
Front Scale
25cm // LL1, A [ B, CI, C ] D, LL3 || LL2
Back Scale: Conversion Tables

S116 Soviet LFAI 250-19 5161-57 1971

Soviet LFAI 250-19 5161-57 1971
Made in USSR/CCCP- LFAI factory, Lenningrad
Front Scale
K, A [ B, S, ST, T, C ] D, DI
Back Scale:
L, LL₁, DF [CF, CIF, CI, C] D, LL₃, LL₂

Soviet-LFAI Aviation Navigator's
REF S531

Soviet-LFAI Aviation Navigator's
Made in USSR
Scales: The Corrected height
Height and speed on the device
Distance
Radiuses of a turn - distances - heights

S552 Soviet-LFAI Artillery

Soviet-LFAI Artillery - 1962
Made in USSR
Front Scale:
1:50000M, 1:25000M // β, N� [Sin, S&T, Tg, N ] N_Q+1, L
Back Scale: [ Sin, S&T, Tg, N ]
Back: Position and spotter formulae
Multiple hairlined Cursor

ISRM LFAI Soviet Military Dual Circular

Soviet Military Dual Circular - 1957
Made in USSR by LFAI, Leningrad
Left Scale: 10000 meter (Sin)
Right Scale: 10000 meter (Tg)
Back: Position and spotter formulae
Actual application unknown at this time

REF Leib Stern Compressor Slide Rule

Leib Stern Compressor Slide Rule - c1957
Made in USSR by LFAI, Leningrad

Designed by Leib (Leonid) Stern. Leib was born in the Ukraine in 1914, and had a long career as a metallurgical engineer in the USSR. He immigrated to Israel in 1987, and had passed away here in 1999. He had the knack for innovation that marks the best engineers, and during his days as a metallurgist he had patented many inventions, including the slide rule shown above.
Archive - Donated to the Nathan Zeldes Collection in Isreal by Leib's daughter.

Manual (Russian) 1.32MB PDF

TU

Minicterctvo Priboroctroeniya credctb avtomatizatsii i cictem yprableniya coyuzelektonmazh
Kievskii ordena Trudovogo Kracnogo Znameni zavod elektronn
Vechiclitelnekh i ypravlyauzhikh mazhni
The Ministry of Instrument-making, means of automation and guidance systems
Union of precise machine and instrument makers
Awarded by the Red Labor Banner
Plant of electronic computational and control machines of Kiev


P198 Soviet TU 25.01.610-72 1972	Soviet TU 25.01.610-72 1972 Made in USSR/CCCP- TU factory - LSLO Open Style Front Scale K, A [ B, CI, C ] D, L Back Slide: [ S2, ST1, T3 ] LSLO/TU Instruction Sheet (Russian) 4.3Mb
P175 Soviet TU 25.01.610-72 1975	Soviet TU 25.01.610-72 1975 Made in USSR/CCCP- TU factory- LSLO Open Style Front Scale K, A [ B, CI, C ] D, L Back Slide: [ S2, ST1, T3 ]
S321 Soviet 250-14P LSLO 5161-72 1977	Soviet 250-14P LSLO 5161-72 1977 Made in USSR/CCCP - LSLO Open Style Front Scale 27cm // K, A [ B, BI, CI, C ] D, S, ST, T₃, L Back Scale [ LL₁, LL₂, LL₃ ] Original Location:USSR Instruction Sheet (Russian) 2.24Mb
S392 Soviet 250-14P LSLO 5161-72 1979	Soviet 250-14P LSLO 5161-72 1979 Made in USSR/CCCP- LSLO Open Style Front Scale 27cm // K, A [ B, BI, CI, C ] D, S, ST, T₃, L Back Scale [ LL₁, LL₂, LL₃ ] Original Location: USSR Instruction Sheet (Russian) 2.24Mb
ISRM Soviet 250-14 LSLO 5161-72 1977	Soviet 250-14P LSLO 5161-72 1977 Made in USSR/CCCP in Kiev - LSLO Open Simplex Front Scale 27cm // K, A [ B, BI, CI, C ] D, S, ST, T₃, L Back Scale: [ LL₁, LL₂, LL₃ ] Original Location: Ukraine
S194 Soviet-LSLO 250-10P 5161-72 1979	Soviet-LSLO 250-10P 5161-72 1979 Made in USSR/CCCP - LSLO Open Style Front Scale 27cm // K, A [ B, CI, C ] D, L Back Scale: [S, ST, Tg ] Back: Blank
S365 Soviet-LSLO 250-10 5161-72 1983	Soviet-LSLO 250-10 5161-72 1983 Made in USSR/CCCP- LSLO Open Style Front Scale 27cm // K, A [ B, CI, C ] D, L Back Scale: [S, ST, Tg ] Cursor: Multiple Hairlines, Kw, Ps, d Back: Blank

SPZ, Voronezh, Russia


P025 Soviet SPZ Pocket 5161-57 1972	Soviet SPZ Pocket 5161-57 1972 Made in USSR/CCCP- SPZ factory Front Scale K, A [ B, CI, C ] D, L Back Slide: [ S, ST, T ]
S208 Soviet SPZ 5161-72 1977	Soviet SPZ 5161-72 1977 Made in USSR/CCCP - SPZ Front Scale K, A [ B, CI, C ] D, L Back Slide: [ S, ST, T ]
REF Soviet Addiator	Soviet Addiator Made in USSR/CCCP - SPZ Archive - Not in Collection

<>h2

Ramenskoye factory, Russia (Moscow region)


S367 Soviet-Ramenskoye 5161-72 1976	Soviet-Ramenskoye 5161-72 1976 Made in USSR/CCCP- Ramenskoye factory, Russia (Moscow region) Front Scale K, A [ B, CI, C ] D, L Back Slide: [ S, ST, T ]

PAMEHCKOE - Ramenskoye Fabreka Ramenskoye Factory - Russia (Moscow region)


S389 Soviet Ramenskoye Fabreka 5161-49 1958	Soviet Ramenskoye Fabreka 5161-49 1958 Made in USSR/CCCP- Ramenskoye factory, Russia (Moscow region) Front Scale 25cm // K, A [ B, CI, C ] D, L \|\| 25cm Back Slide: [ Sin, S&T, Tg ]
P204 Soviet Ramenskoye Fabreka 5161-57 1961	Soviet Ramenskoye Fabreka 5161-57 1961 Made in USSR/CCCP- Ramenskoye factory, Russia (Moscow region) Front Scale K, A [ B, CI, C ] D, L Back Slide: [ Sin, S&T, Tg ]

STP VMP - Voronezh, Russia


S404 Soviet STP VMP 5161-57 1961	Soviet STP VMP 5161-57 1961 Made in USSR/CCCP- STP VMP factory Voronezh, Russia Front Scale 25cm // K, A [ B, CI, C ] D, L \|\| 25cm Back Slide: [ Sin, S&T, Tg ]


C01_USSR Artillery Ranging	C01_USSR Artillery Ranging Made in USSR Front Scale tg, tg, 10K [Sin1-00, Sin0-10, 10K] Tables Archive - No longer in collection

Slide Rule Watch - Model KL-1's

Texnichesko-Cbetovaya Organizatsia "Rassvyet"
Technical and Lights Company "Sunrise"

MLTZKP: Moscow Experimental [or "Pilot"] Plant for Control Devices "Kontrolpribor"

C10 Soviet KL-1 Slide Rule watch Soviet KL-1 Slide Rule watch
Made in USSR 5cm diameter
Front Scale
Instruction Sheet (Russian) 1.9Mb
Instruction Sheet (English) 138Kb

Soviet KL-1 Slide Rule watch
ISRM 04.09.27.03 Soviet KL-1 Slide Rule watch
Made in USSR 5cm diameter
Front Scale
Insert (Russian) 990Kb
Instruction Sheet (English) 138Kb

А Б В Г Д Е Ж З И Й К Л М Н О П Р С Т У Ф Х Ц Ч Э Ю Я ы

Russian Alphabet

Russian Keyboard

I'd like to thank the following persons for helping me in translations
Russian: Nicolas M. Winowich
Russian: Nic A. Benner (Broomfield, CO)
Russian slide rule nomenclature: Alex Zyblev (Odintsovo, Russia)
Ukranian: George Sawzchen (Ft. Collins, CO), my brother-in-law
