SIC slide rules were manufactured for Scientific Instruments in Berkeley, California by Japanese manufacturers Relay/Ricoh and Concise. SIC had custom models which added scale labels to the cursors, a handy, yet costly, technique which was never duplicated on other brands or by other manufacturers. Note that on slide rules that have the SIC Diamond Logo, the rules have serial numbers but do not have the pi (π) gauge mark on the A and B scales found on earlier slide rules without logos. The linear SIC Models numbers are normally a Relay model number with an extra zero (Relay 102 = SIC 1020). The SINCO logo was used in 1965
Note: Almost all the slide rules shown in this gallery were gifted to the Computer History Museum in Mountainview, California so we are left with virtual images (Ref: Pxxx, Cxx, Sxxx). If you have a physical replacement for the ISRM archives, your gift would be appreciated by all.


SIC 120 (Version 1)4"(Rototrig 200)
REF		 SIC 120 (Version 1)4"(Rototrig 200) 1962
Made in Japan for Scientific Instruments Co.
Front Scale: K, A, D ( C, CI, EI (spiral) )
Back Scale: L, DI, D T, S, T, S, T, T&S
Stock Dimensions (mm): 108 Dia x 4
Box


SIC 120 4"(Rototrig 200)
ISRM 21.06.10.12
 SIC 120 4"(Rototrig 200) (Logo)1962
Made in Japan for Scientific Instruments Co.
Front Scale: K, A, D ( C, CI, EI (spiral) )
Back Scale: L, DI, D T, S, T, S, T, T&S
Cursor: has labels with TS Stock Dimensions (mm): 108 Dia x 4
Bob Dehn's Collection gifted by wife Fran (McGroary) Dehn of Menlo Park, California.
Robert "Bob" Dehn (1941-2000) graduated from UC Berkeley with a degree in chemistry. Following his graduation, Bob started work as a pharmaceutical chemist at Stanford Research Institute, which later became SRI International. It was there that he spent his entire professional career. It was also at SRI that he met his wife of 52 years, Fran McGroary. After receiving his MBA from Santa Clara University, Bob moved into marketing and business development for the Life Sciences Division of SRI where he continued until his retirement in 2007..Bob began collecting with his first slide rule while studying at UC Berkeley. During his career he continued to collect from colleagues, antique shows and swaps.


SIC 120 (Version 1)4"
C25		 SIC 120 (Version 1)4"
Made in Japan for Scientific Instruments Co.
Front Scale: K, A, D ( C, CI, EI (spiral) )
Back Scale: L, DI, D T, S, T, S, T, T&S
Stock Dimensions (mm): 108 Dia x 4
Box


SIC 120 (Version 2)
REF		 SIC 120 (Version 2) - 1962
Made in Japan for Scientific Instruments Co. - 10.8cm Dia
Front Scale: K, A, D ( C, CI, EI (spiral) )
Back Scale: L, DI, D T, S, T, S, T, TS
Archive - Ted White Collection


SIC 120-D 1963 Duplex 4"
C38		 SIC 120-D 1963 Duplex 4"
Made in Japan for Scientific Instruments Co.
Front Scale: K, A, D ( C, CI, B, EI (spiral) )
Back Scale: L3, L2, L, DI, D (C, T, S, T, S, T, T&S)


SIC 130 (Version 1) 4-3/8"
REF		 SIC 130  4-3/8"
Made in Japan for Scientific Instruments Co.
Front Scale: K, A, D ( C, CI, EI (spiral) )
Back Scale: L, DI, D T, S, T, S, T, T&S
Stock Dimensions (mm): 108 Dia x 4
Note: This is the same exact SR as the 120, There may have been some early model number changes when the company first got started
Box
Instructions 8.15 MB


SIC 151 MultiLog (1961)
REF 		SIC 151 MultiLog (date code J.S.-3)
Made in Japan by Relay/Ricoh for ALVIN
Dimensions: 35cm x 4.7cm x 0.6cm, 131gm
Front Scale (Extended)
LL0, L, K, A [ B, S, ST, T, C ] D, DI, P, LL0
Back Scale (Extended)
LL1, LL2, LL3, DF [CF, CIF, CI, C ] D, LL3, LL2, LL1
Multilined Cursor: Kw, HP, etc.
Scan provided by the Steve Seale Collection, Nashville, Tennessee


SIC (Relay) 153 Master Trig
ISRM 09.01.12.20 		SIC (Relay) 153 Master Trig
Made in Japan by Relay dc HS-2 (1957) for S.I.C. (Scientific Intruments Inc) in Berkely, CA
Front Scale: K, A [ B, S, ST, T C ] D, DI
Back Scale: L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Donated by David Hecht, Alexandria, VA


SIC 250 3"(SINCO Rototrig 100)
ISRM 18.04.13.01		 SIC 250 3"(SINCO Rototrig 100)
Made in Japan for Scientific Instruments Co. 1962
Front Scale: K, A, D ( C, CI, L )
Back Scale: D, T, S, T<45, S<45, T&S<5.8
Stock Dimensions (mm): 81 Dia x 3
Donated by Barbara Oppliger, belonged to husband Melvin Oppliger.
The photo of Melvin Eugene Oppliger (c1941-2017) shows him on his way to Okinawa. On his second tour, he was stationed in Honolulu, Hawaii in support of the NIKE missle there. Gene served six years in the Army and opted out in 1966 after he met and married Barbara. He worked for Datsun from 1970 thru 1983 mostly as a parts rep, that is where his love for the 510 sedan began. He retired from John Snyder Tool Company in 2007 after 17 years as a automotive tool rep. He loved anything car related and driving. During retirement he enjoyed traveling with his wife of 51 years going cross-country in their motorhome.


SIC 250 3"(SINCO Rototrig 100)
ISRM 15.08.29.06
 SIC 250 3"(SINCO Rototrig 100)
Made in Japan for Scientific Instruments Co. 1962
Note: there are two Patent:Numbers shown on the slide rule, 440028 and 130076. Neither of these show up in the USA or worldwide patent databases.
Front Scale: K, A, D ( C, CI, L )
Back Scale: D, T, S, T<45, S<45, T&S<5.8
Stock Dimensions (mm): 81 Dia x 3
Gift Of Marylyn (Stubbs) Ulrich For George Ulrich.
George W Ulrich (1938-2015) was one of the first to attend Marquette High School and Alton High School simultaneously. He took his skills in design and construction to McDonnell Aircraft's spacecraft and defense programs while attending Washington University night school. He retired from Boeing in 2003. During those years he served in the Army.In 1964 he married Alton resident Marilyn Stobbs and moved to Florissant, MO but retained his Knights of Columbus #460 membership.


SIC 300B Concise (SIC 250D Prototype)
ISRM 21.08.07.18		 SIC 300B Concise (SIC 250D Prototype)
Made in Japan by Concise for SIC - 1961
Front Scale: K, A, D ( C, CI, B, L )
Back Scale: LL3, LL2, D ( C, S Cos, T1 Cot1, T2 Cot2, ST
Stock Dimensions (mm): 111 Dia x 3
Gift Of William Lisowski.


SIC-Relay 102 (SIC 1020) Basic Beginner JK-3
S520 		SIC-Relay 102 (Early prototype of SIC 1020)
Made in Japan by Relay/Ricoh for SIC - code HK-3
Front Scale: A, [ B, CI, C ] D, K
Back Scale: [ S, L, T ] D
Stock Dimensions (mm): 280 x 28.5 x 8.5
Case Logo


SIC-Relay 550 (early prototype of SIC 5500)
P104 		SIC-Relay 550 - Early prototype of SIC 5500)
Made in Japan by Relay/Ricoh for SIC - code HK-3
Front Scale: A, [ B, S, T, C ] D, K
Back Scale: DF [ CF, CI, C ] D, L
Stock Dimensions (mm): 175 x 24.5 x 4.8


SIC 1020 Basic Beginner
S519 		SIC 1020 Basic Beginner - early
Made in Japan by Relay/Ricoh for SIC - code JK-4
Front Scale: A, [ B, CI, C ] D, K
Back Scale: [ S, L, T ] D
Stock Dimensions (mm): 280 x 28.5 x 8.5
Case Logo


SIC 1020 Basic Beginner (Logo)
S521 		SIC 1020 Basic Beginner sn90306
Made in Japan by Relay/Ricoh for SIC - code HK-3
Front Scale: A, [ B, CI, C ] D, K
Back Scale: [ S, L, T ] D
Stock Dimensions (mm): 280 x 28.5 x 8.5


SIC 1510 Astrolog - Adv. Gen. Eng. (1961)
ISRM 22.10.15.02		 SIC 1510 Astrolog (pre Diamond Logo) no S/N 1961
Made in Japan by Relay/Ricoh for Scientific Instruments Company (SINCO)
Note: narrow rectangular cursor blocks.
Front Scale (extended)
LL-0, L, K, A [ B, S Cos, ST, T Cot, C ] D, DI, P, LL0
Back Scale: LL-1, LL-2, LL-3, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1
Stock Dimensions (mm): 351 x 47 x 7 Gift of David Zoumaras of San Diego, California..


SIC 1510 Astrolog - Adv. Gen. Eng.
S511		 SIC 1510 Astrolog (early) No S/N. Advanced General Engineering.
Made in Japan by Relay/Ricoh for SIC - 1961 Logo
Front Scale (extended)
LL-0, L, K, A [ B, S Cos, ST, T Cot, C ] D, DI, P, LL0
Back Scale: LL-1, LL-2, LL-3, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1
Originally part of SIC retail display, Factory stock.
Stock Dimensions (mm): 355 x 47 x 7


SIC 1510 Astrolog (w/Logo) - Adv. Gen. Eng.
ISRM 22.07.06.46		 SIC 1510 Astrolog (w/Logo) sn30446
Made in Japan by Relay/Ricoh for SIC - 1961
Note: Scale labels imprinted on cursor lens.
Front Scale (extended)
LL-0, L, K, A [ B, S Cos, ST, T Cot, C ] D, DI, P, LL0
Back Scale: LL-1, LL-2, LL-3, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1
Stock Dimensions (mm): 351 x 47 x 7 Gift of Cindy Tate, Bozeman, Monatna Victor B. Tate II Collection.


SIC 1520
S515		 SIC 1520 Master Trig (early)
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: K, A [ B, S Cos, ST, T Cot, C ] D, DI
Back Scale: DF [ CF, CIF, CI, C ] D, L
Stock Dimensions (mm): 322 x 40 x 7


SIC 1520 Multiphase Deca Trig (Logo)
ISRM 14.01.10.43		 SIC 1520 Multiphase DecaTrig - S/N 40157
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: K, A [ B, S Cos, ST, T Cot, C ] D, DI
Back Scale: DF [ CF, CIF, CI, C ] D, L
Stock Dimensions (mm): 320 x 40 x 7
Original Owner: Ed Zimmer, written on flap of sleeve. Initials on end of stock.
Gift of the Bill Wehrend Collection, Palo Alto, California.


SIC 1530 Technilog
S513		 SIC 1530 Technilog - (early)
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: LL0, K, A [ B, S Cos, ST, T Cot, C ] D, DI, LL00
Back Scale: L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Stock Dimensions (mm): 322 x 39.5 x 7


SIC 1530 Technilog (Logo)
S514		 SIC 1530 Technilog - S/N 30805
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: LL0, K, A [ B, S Cos, ST, T, T Cot, C ] D, DI, LL00
Back Scale: L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Stock Dimensions (mm): 319 x 40.5 x 7


SIC 1530 Technilog
ISRM 09.01.12.119 		SIC 1530 Technilog
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: LL0, LL00, A [ B, K, CI, C ] D, S Cos, ST, T Cot
Back Scale: L, LL1, DF [ CF, CIF, CI C ] D, LL3, LL2
Stock Dimensions (mm): 319 x 40.5 x 7
Donated by David Hecht, Alexandria, VA


SIC 1530 Technilog (Logo)
ISRM 09.01.12.120 		SIC 1530 Technilog
Made in Japan by Relay/Ricoh for SIC - 1964
Front Scale: LL1, K, A [ B, T, T Cot, ST, S Cos, C ] D, DI, LL1, L
Back Scale: LL2, LL3, DF [ CF, CIF, CI, C ] D, LL3, LL2
Stock Dimensions (mm): 319 x 40.5 x 7
Donated by David Hecht, Alexandria, VA


SIC 1570 Electro Vector Log Log
S510		 SIC 1570 Electro Vector Log Log (early)
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: Sh1, Sh2, A [ B, K, Th, C ] D, Tr1, Tr2, db
Back Scale (Note: special LL' scale on C scale)
Sr, Sθ Sθ, P', P [ Q, CF, CI, C  LL'  ] D, DF, LL2, LL3
Originally part of SIC retail display, Factory stock.
Stock Dimensions (mm): 355 x 47 x 7


SIC 1570 Electro Vector Log Log (Logo)
S509		 SIC 1570 Electro Vector Log Log - sn30512
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: Sh1, Sh2, A [ B, K, Th, C ] D, Tr1, Tr2, db
Back Scale (Note: special LL' scale on C scale)
Sr, Sθ Sθ, P', P [ Q, CF, CI, C LL' ] D, DF, LL2, LL3
New Factory Box
Stock Dimensions (mm): 351 x 47 x 7


SIC 1580 Electro Vector Log Log DecaTrig
S517		 SIC 1580 Electro Vector Log Log DecaTrig (early)
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale (extended)
Sh2, Sh1, Th, A [ BI, S Cos, T Cot, CI, C ] D, LL3, LL2, LL1
Back Scale: X2, X1, P2, P1 [ Q, Y, L, LX, I ] I, Lθ1<45  Lθ1>45, Lθ2>45 Lθ2<45, LY
Originally part of SIC retail display, Factory stock
Stock Dimensions (mm): 355 x 46.5 x 7


SIC 1580 Electro Vector Log Log DecaTrig (Logo)
S518		 SIC 1580 Electro Vector Log Log DecaTrig sn30152
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale (extended)
Sh2, Sh1, Th, A [ BI, S Cos, T Cot, CI, C ] D, LL3, LL2, LL1
Back Scale: X2, X1, P2, P1 [ Q, Y, L, LX, I ] I, Lθ1<45  Lθ1>45, Lθ2>45 Lθ2<45, LY
New Factory Box
Stock Dimensions (mm): 352 x 46.5 x 7


SIC 1610 1962 5"(Rotolog 400)
C31		 SIC 1610 (logo) 1962 5"(Rotolog 400)
Made in Japan for Scientific Instruments Co.
Front Scale: LL3, LL2, LL1, LL0, K, A, D ( C, CI, B, EI(spiral) )
Back Scale: LL03, LL02, LL01, LL00, L, DI, D, T, S, T, S, T, TS )
New Factory Box
Stock Dimensions (mm): 128 Dia x 4


SIC 1610 1962 5"(Rotolog 400)
C33		 SIC 1610 (logo) 1962 5" (Rotolog 400)
Made in Japan for Scientific Instruments Co.
Front Scale: LL3, LL2, LL1, LL0, K, A, D ( C, CI, B, EI(spiral) )
Back Scale: LL03, LL02, LL01, LL00, L, DI, D, T, S, T, S, T, TS )
New Factory Box
Stock Dimensions (mm): 128 Dia x 4


SIC 1610-D Duplex 5" (Rotolog 500)
C34		 SIC 1610-D Duplex 1963 5" (Rotolog 500)
Made in Japan for Scientific Instruments Co.
Front Scale: LL3, LL2, LL1, LL0, K, A, D ( C, CI, B, EI(spiral) )
Back Scale: LL03, LL02, LL01, LL00, P, L, DI, D ( C, T, S, T, S, T, TS )
Stock Dimensions (mm): 128 Dia x 4
Box


P246 SIC 4030 Junior Mannheim - early
P246 		SIC 4030 Junior Mannheim - early
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: 4in // A, [ B, CI, C ] D ||10cm
Back Scale: [ S, L, T ] D
New Factory Box
Stock Dimensions (mm): 118 x 19[23] x 6


SIC 4030 Junior Mannheim (Logo)
ISRM 21.08.07.36 		SIC 4030 Junior Mannheim - sn30151
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale: 4in // A, [ B, CI, C ] D ||10cm
Back Scale: [ S, L, T ] D
New Factory Retail Box
Stock Dimensions (mm): 118 x 19[23] x 6
Gift Of William Lisowski


SIC 4500 Junior Multiphase
P250 		SIC 4500 Junior Multiphase
Made in Japan by Relay/Ricoh for SIC Berkeley, California
Front Scale: A, [ S, L, T ] D
Back Scale: DF [ CF, CI, C ] D
New Factory Box
Stock Dimensions (mm): 155 x 25 x 5


SIC - Scientific Instruments 4500
P243 		SIC 4500
Made in Japan by Relay/Ricoh for SIC Berkeley, California
Front Scale: A, [ S, L, T ] D
Back Scale: DF [ CF, CI, C ] D
Originally part of SIC retail sales display
Stock Dimensions (mm): 155 x 25 x 5


SIC 4500 Junior Multiphase (Logo)
P251 		SIC 4500 Junior Multiphase - sn30461
Made in Japan by Relay/Ricoh for SIC
Front Scale: A, [ S, L, T ] D
Back Scale: DF [ CF, CI, C ] D
New Factory Box
Stock Dimensions (mm): 155 x 25 x 5


SIC 5050 Pocket Mannheim
P248 		SIC 5050 Pocket Mannheim - early
Made in Japan by Relay/Ricoh for SIC - (c)1961 (no SIC Logo)
Front Scale: 13cm // A, [ B, CI, C ] D, K || 5in
Back Scale: [ S, L, T ] D
New Factory Box
Stock Dimensions (mm): 148 x 24[29] x 7


SIC 5050 Pocket Mannheim (Logo)
P249 		SIC 5050 Pocket Mannheim sn40116
Made in Japan by Relay/Ricoh - (c)1961 (SIC Diamond Logo on face)
Front Scale: 13cm // A, [ B, CI, C ] D, K || 5in
Back Scale: [ S, L, T ] D
New Factory Box
Stock Dimensions (mm): 148 x 24[29] x 7


SIC 5050 Pocket Mannheim (c)1961
ISRM 11.11.17.08		 SIC 5050 Pocket Mannheim (c)1961
Made in Japan by Relay/Ricoh (SIC Diamond Logo on back)
Front Scale: 13cm // A [ B, CI, C ] D, K || 5in
Back scale: [S, L, T ]
Back: Calculating Guide formulas
Stock Dimensions (mm): 148 x 24[29] x 7
Donated by David Hecht, Alexandria, Virginia


SIC - Scientific Instruments 5500
P242 		SIC 5500
Made in Japan by Relay/Ricoh (#550) branded for SIC
Front Scale: A, [ B, S, T, C ] D, K
Back Scale: DF [ CF, CI, C ] D, L
Originally part of SIC retail sales display
Stock Dimensions (mm): 175 x 24.5 x 4.8


SIC 5500 Pocket Multiphase
P252 		SIC 5500 Pocket Multiphase early
Made in Japan by Relay/Ricoh for SIC
Front Scale: A, [ B, S, T, C ] D, K
Back Scale: DF [ CF, CI, C ] D, L
New Factory Box


SIC 5500 Pocket Multiphase
P253 		SIC 5500 Pocket Multiphase sn31086
Made in Japan by Relay/Ricoh for SIC
Front Scale: A, [ B, S, T, C ] D, K
Back Scale: DF [ CF, CI, C ] D, L
New Factory Box


SIC 5510 Astrolog 5
P241		 SIC 5510 Astrolog 5 (early)
Made in Japan by Relay/Ricoh for SIC - 1961
Front Scale (extended)
LL-0, L, K, A [ B, S Cos, ST, T Cot, C ] D, DI, P, LL0
Back Scale: LL-1, LL-2, LL-3, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1
New Factory Box
Stock Dimensions (mm): 170 x 35.5 x 5


SIC 5510 Astrolog 5 (Logo)
ISRM 21.08.07.37		 SIC 5510 Astrolog 5 - Advanced General Engineering
Made in Japan by Relay/Ricoh for SIC - 1961. sn90043.
Front Scale (extended)
LL-0, L, K, A [ B, S Cos, ST, T Cot, C ] D, DI, P, LL0
Back Scale: LL-1, LL-2, LL-3, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1
Stock Dimensions (mm): 170 x 35.5 x 5
Gift Of William Lisowski

Scientific Instruments Company Ephemera


Two types of Packaging
Yellow/blue most recent
Circular SR Packaging
Orange SINCO most recent
SINCO Ad - August 1965
SIC Models
1966
SINCO Circular
Rotorules
SINCO
Slide Rules
Copyright © 2003-
International Slide Rule Museum
