This American slide rule manufacturer was founded in 1885 by Eugene Dietzgen. The first manufacturing company opened in 1893 producing T-squares, wooden triangles, drawing boards, hectograph inks, surveying instruments, blue print and Van Dyke papers, Dietzgen's historic line of engineering products. In 1908 the company acquired its own drafting instruments factory in Germany and introduced their "Lifetime Service Policy" on drafting Instruments. The company later OEM'ed slide rules from Faber-Castell and other engineering items and drafting instruments from Germany (Ecobra) and from Japan (Ricoh) for the American Market. Often mistaken for K&E slide rules, as many parts are interchangeable as the physical dimensions and construction are similar. The main factory and head office was in Chicago, Illinois, and branch offices were in New York, San Francisco, New Orleans, Pittsburgh and Los Angeles.

Dietzgen slide rules with aluminum stocks (such as the 1738 Multilog Type-M) were manufactured by Ecobra in Germany. Both companies were involved in their respective war efforts during WWII (Dietzgen was a US company, Ecobra a German one). After the war, Dietzgen began selling Ecobra rules as an exclusive branded U.S. distributer until the 1970s, when Dietzgen bought Ecobra. Ref: Bill Wheaton, a long-time Dietzgen employee, Dieter von Jezierski, and Eric Marcotte. Models with bamboo stocks (such as the 1737 DecimalTrig) were made by Ricoh.




Dietzgen 1742 20 inch - Phillips

REF L04

Dietzgen 1742 20 inch - Phillips
Made in USA
Front Scale: 20inch // E, A [ B, R, C ] D || 50cm
Back Slide: [ S, L, T ] Back: Equivalents


Dietzgen 1742 20 inch Phillips - Magnifying Cursor

ISRM 20.09.18.01

Dietzgen 1742 20 inch Phillips - Magnifying Cursor
Made in USA
Front Scale: 20inch // E, A [ B, R, C ] D || 50cm
Back Slide: [ S, L, T ] Back: Equivalents


Dietzgen 1752P 20 inch - Maniphase

ISRM 15.03.05.01
Dietzgen 1752P 20 inch - Maniphase
Made in USA
Front Scale: 20inch // K, A [ B, CI, C ] D || 50cm
Back Slide: [ S, L, T ] Back: Equivalents
Gift of Ed Millis, Dallas, Texas.


Dietzgen 1762 20 inch - Mannheim, All Glass Cursor

ISRM 13.10.10.01

Dietzgen 1760 10" Version

Dietzgen  1762 20 inch - Mannheim, All Glass Cursor
Made in USA
Note: the All Glass Cursor, Patent US 1855523, is being shared with the 1760 10" version, ISRM 13.10.25.01
Front Scale: 20inch // A [ B, C ] D || 50cm
Back Slide: [ S, L, T ] Back: Equivalents



Dietzgen Mannheim (D&P) Improved Slide Rule
Patent June 28, 1898

ISRM 2012.10.22.01


Major Paul C. Allred
Fort Lewis, Washington

Case
Dietzgen Mannheim (D&P) Improved Slide Rule
Patent June 28, 1898

Made in Germany by Dennert and Pape for Eugene Dietzgen Co.
Front Scale
10inch // A [ B, C ] D || 27cm
Back Scale
[ S, L, T ] Back: Equivalents
Note: Very early 'railroad track' style divisions
Original Owner: F.P. Sisson (name on case and in well), then owned and used by Major Paul C. Allred, US Army.
Donated by Pamela Lanier Wolfe Browne, Kernersville, North Carolina
This slide rule was acquired in Germany and used by Major Paul C. Allred, US Army. (1916 - 1979). Paul joined the Army on April 11, 1934. He served as a surveyor in the Infantry Artillery most of his career in the battles and campaigns in Normandy, Northern France, Rhineland, Ardennes, Central Europe, and Korea. He was awarded the Eamet Campaign Medal with 5 Bronze stars, Good Conduct Medal, WWII victory medal, Koren Service Medal, Bronze Star Medal with oak leaf cluster, and a National Defense Service Medal. He retired in 1962. He thenb worked as a surveyor for the North Carolina Departement of Transportation, Greesboro, until retirement in 1977. Sometime while working for the state he began using a Texas Instrument calculator, but still checked his answers on his trustworthy slide rule. (Paul was Pamela's Godmother's husband)
Note: Pamela Browne is the widow of Harry Edson Browne (1933-2006). Harry Browne was an inspirational speaker who wrote 19 books that sold more than 2 million copies. In 1996 and 2000 he was the nominee of the Libertarian Party for President of the United States. Pamela's personal slide rule, a Fullerton-Acu 1240, along with photo, may be seen in the Acumath gallery.


Eugene Dietzgen Pocket Slide Rule

REF
Eugene Dietzgen Pocket Slide Rule
Made in Germany - c 1915
Front Scale
A [ B, C ] D
Back Scale
5in [ S, L, T ] 12.5cm
Archive - Scan provided by Cassou Olivier Collection, France


Dietzgen 1725 Maniphase Vector Trig Type Log Log

ISRM 14.05.01.04
Dietzgen 1725 Maniphase Multiplex Vector Trig Type Log Log c1945
Made in USA - 24 scales s/n 113981
Front Scale
Sh2, Sh1, Th, A [ B, T<45 Cot, T>45 Cot, ST, S Cos ] D, DI, LL01, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, CI, C ] D, LL3, LL2
Gift of Phillip Rodley, Upperhutt, New Zealand



Dietzgen N1725 Microglide Vector Type Log Log

ISRM 11.11.17.03
Dietzgen N1725 Microglide Vector Type Log Log c1948
Made in USA - 28 scales s/n 013933
Note: New scale arrangements from "1725" vs the new "N1725".
Front Scale
Th, Sh2, Sh1, A [ B, T<45 Cot, T>45 Cot, ST, S Cos ] D, DI, K
Rear Scale
LL01, LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2, LL1


Dietzgen N1725 Microglide Vector Log Log (1959)

ISRM 21.04.08.01




Receipt from 7-1-1959
Dietzgen N1725 Microglide Vector Log Log 1959
Made in USA - 28 scales s/n 095352
Note: Micromatic label on Slide
Front Scale
Th, Sh2, Sh1, A [ B, T<45 Cot, T>45 Cot, ST, S Cos ] D, DI, K
Rear Scale
LL01, LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2, LL1
Original Owner: Harold J. Wise ( 1939-2016).
Gift of Susan H. Wise of Evanston, Illinos.
Harold J. Wise received his ME degree from the University of Cincinnati in 1962. He profoundly appreciated the real world experience he received in the co-op segments of UC's curriculum. He purchased his Dietzgen N1725 slide rule while on a co-op rotation at General Electric's Evendale facility in 1959. He went on to receive his MBA in Marketing and Production from Northwestern's Kellogg School of Business in 1964. Then, following active duty military service, he began his career at General Electric in the Aircraft Engine Division. In the early years of his career he completed the requirements for his P.E. designation, submitting his paper on "e;Strengthening the Engineering/Marketing Relationship."e; Following the time at GE, Harold worked as a marketing executive for several manufacturers of technical products. For more than a decade before retirement he was with United Conveyor Corporation in Waukegan, Illinois as Manager, Parts and Product Sales and also, for a period of time, as Director of Production. A source of pride and gratification for him was the decision of his oldest grandson to study Mechanical Engineering. Harold enjoyed retirement until he passed away in 2016.


Dietzgen N1725 Microglide Vector Log Log (1964)

ISRM 15.02.25.01

Dietzgen N1725 Microglide Vector Log Log c1964
Made in USA - 28 scales s/n 112565
Front Scale
Th, Sh2, Sh1, A [ B, T<45 Cot, T>45 Cot, ST, S Cos ] D, DI, K
Rear Scale
LL01, LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2, LL1
Gift of David DeSpain,of Fort Worth, Texas.. He tells us about it in his own words:
"The slide rule was a high-school graduation present in 1964 for (Farmington (MO) Senior High School) from my parents Gaines Wagner (GW) and Linda DeSpain. It was ordered for them by Willard Vandegriff, a civil engineer and PE in Farmington. I believe the list price was $28.00 and Mr. Vandegriff got it for $20.00 through his suppliers. I used it at the University of Missouri-Rolla, formerly University of Missouri School of Mines and Metallurgy, now Missouri University Science and Technology (MUST). I graduated with a Bachelor of Science degree in Electrical Engineering in 1969. Later I used the slide rule at Columbia Broadcasting System (KMOX Radio in St. Louis), while in the US Army at White Sands Missile Range in New Mexico. Sometime in the mid-70's, I put together a kit scientific calculator from Sinclair, which had all the trig and log and exponential functions, and operated only in scientific notation. I retired from the Voice of America, or Broadcasting Board of Governors, in 2008, where I was their in-house expert on high power (100, 250, 500, and 1000 KiloWatt) ShortWave and MediumWave (AM) transmitters."


Dietzgen B-1725 (Bamboo) Vector Type Log Log

REF
Dietzgen B-1725 (Bamboo) Vector Type Log Log c1965
Made in Japan by Ricoh for Dietzgen - 25 scales
Front Scale
Th, Sh2, Sh1, A [ B, T<45 Cot, T>45 Cot, ST, S Cos ] D, DI, K
Rear Scale
LL01, LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2, LL1
Archive: Larry Kehl collection


Dietzgen 1731 Trigonometric  Log Log

REF S453
Dietzgen 1731 - Trigonometric  Log Log - s/n 401056
Made in USA - Maniphase Multiplex  -20 scales
Note: Degrees divided in 12 divisions - minutes and seconds. The N1731 below has decimal degrees.
Front Scale
LL01, K, A [ B, T Cot, ST, S Cos ] D, L, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, CI, C ] D, LL3, LL2
Original Owner: John Coonrod



Dietzgen N1731 Micromatic Trigonometric Log Log

ISRM 14.07.02.96
Dietzgen N1731 Micromatic Trigonometric Log Log s/n 084303
Made in USA - 24 scales
Note: Degrees divided in 10 divisions, Decimal degrees. The 1731 above has degrees in minutes and seconds.
Front Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos ] D, L, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, CI, C ] D, LL3, LL2


Dietzgen 1732 Decimal Trig Log Log

ISRM 20.08.15.06
Dietzgen 1732 Maniphase Multiplex Decimal Trig Type Log Log - No s/n
Made in USA - Early all-glass cursor 22 scales
Note: Degrees divided in 10 divisions - decimals
Front Scale: LL0, LL00, A [ B, T Cot, ST, S Cos ] D, DI, K
Rear Scale: L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Gift of Robert Carlisle of Nederland, Colorado.
Note: The glass lens is not original.


Dietzgen 1732 Decimal Trig Log Log

ISRM 20.08.13.01

Dietzgen 1732 Maniphase Multiplex Decimal Trig Type Log Log - No s/n
Made in USA -Should have the Early all-glass cursor, Has K&E Cursor.
Note: Degrees divided in 10 divisions - decimals. 22 scales
Front Scale: LL0, LL00, A [ B, T Cot, ST, S Cos ] D, DI, K
Rear Scale: L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Gift Of Valerie Christiansen nee Thompson. Belonged To Father Tommy Thompson.
Valerie Christiansen writes: "My father H.M. Tommy Thompson, had this Dietzgen slide rule for many years. I remember it among his most important tools. ...He had his name all over it so no one would steal it.He taught me how to use it. My father was a Dining Room Steward for Atlantic Coastline, Sante Fe and later Amtrak railroads. He trasured his time at home.and would craerte many projects so he would not have to leave the house. He would be pleased that I found a home for it among people who still value the idea of a good project."


Dietzgen 1732 Decimal Trig Log Log

ISRM 12.01.10.02
Dietzgen 1732 Maniphase Multiplex Decimal Trig Log Log - s/n 536054
Made in USA - Early cursor, 22 scales
Note: Degrees divided in 10 divisions - decimals
Front Scale
LL0, LL00, A [ B, T Cot, ST, S Cos ] D, DI, K
Rear Scale
L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Typical Retail Box


Dietzgen 1732 Decimal Trig Log Log

ISRM 17.05.02.41
Dietzgen 1732 - Decimal Trig Log Log - sn527230
Made in USA - Redesigned all-metal framed cursor, 22 scales
Note: Degrees divided in 10 divisions - decimals, Exponent (e-.001 example) labels
Front Scale: LL0, LL00, A [ B, T Cot, ST, S Cos ] D, DI, K
Rear Scale: L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Gift of Mike Weaver, UK


Dietzgen 1732 Decimal Trig Log Log

ISRM 17.07.15.01

Dietzgen 1732 - Decimal Trig Log Log - s/n 563114 (c1951)
Made in USA - all-metal framed cursor, 22 scales22 scales
Note: Degrees divided in 10 divisions - decimals. Revised Exponent ([e-.001 example) labels
Front Scale
LL01[e-0.01, L, K, A [ B, T Cot, ST, S Cos ] D, DI, LL1[e0.01
Rear Scale
LL02[e-0.1, LL03[e-1.0, DF [ CF, CIF, CI, C ] D, LL3[e1.0, LL2[e0.1
Gift of Bill R. Teer of Fairfax, Virginia, who used this in college and in his career.

Bill Graduated in 1955 from Texas A&M with a Bachelors Degree in Mechanical Engineering. His first job was with Westinghouse at the Bettis Atomic Power Laboratory in Pittsburgh. The lab's mission was (and is) to develop the reactors for the nuclear navy. He received an MBA from the University of Pittsburgh. and in 1964 worked 10 years for United Nuclear Corporation which sold uranium and manufactured reload fuel for civilian power reactors. Bill relocated Transnuclear, Inc. which was involved in the transport and storage of spent nuclear fuel and other radioactive materials. In 1991, he moved to Virginia to work for a DOE contractor on the Yucca Mountain Project, which was supposed to take title to all spent nuclear fuel from civilian and military reactors and permanently dispose of it in the Nevada desert. (Funding for this project was killed by Obama in 2008.) Bill retired in March of 2006 and has been cruising and playing competitive bridge since then with his wife of 59 years. Bill endowed a scholarship in the Robert G. Cochran Scholars Program for nuclear engineering undergraduates at Texas A&M University.



Dietzgen 1732 Decimal Trig Log Log

REF S454
Dietzgen 1732 - Decimal Trig Log Log - s/n 574062
Made in USA - c1956  -21 scales - Re-arranged Text
Note: Degrees divided in 10 divisions - decimals. Serial number on bottom of the scales.
Front Scale
LL01[e-0.01, L, K, A [ B, T Cot, ST, S Cos ] D, DI, LL1[e0.01
Rear Scale
LL02[e-0.1, LL03[e-1.0, DF [ CF, CIF, CI, C ] D, LL3[e1.0, LL2[e0.1
Case labeled "Dietzgen Germany" Original owner: Michael P. Taylor, retired Director Dow Chemical. Graduated Univ of Houston, TX. Taught at TAMU and UH. Designed/Built the Houston Dow Center &Dow Chemical plant in Toronto.


Dietzgen N1732 Micromatic Decimal Trig Log Log

ISRM 14.09.21.03


Insert

Dietzgen N1732 Micromatic Trigonometric Log Log s/n 585550
Made in USA - 25 scales. Laminated mahony edges
Note: Degrees divided in 10 divisions, Decimal degrees. The 1731 above has degrees in minutes and seconds.
Front Scale: LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos ] D, DI, LL1
Rear Scale: LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2
Gift of Edward T. Wright of Odenton, Maryland
Edward Wright received his B.A. with Honors in Mathematics from Rhodes College (formerly Southwestern at Memphis) in 1968, followed by his Ph.D. in Mathematics from the University of Notre Dame in 1973. Ed's thesis was on compact Kahler manifolds that admit Killing vector fields. After graduate school Dr. Wright was a visiting assistant professor at Notre Dame for one school year,then worked as an (applied) mathematician for the Department of Defense for 39 years. Ed retired 2014. Ed writes: "The only time I ever used a slide rule was in high school physics (1963/64). I started collecting them off of Ebay in the 2004/5 time period. I continue to marvel at how much was accomplished with these instruments. I am in the process of down sizing the modest collection that I have, and wanted them to go some place that will preserve this part of the technology."


Dietzgen 1733 Polymath Decimal Trig Log Log

REF S287
Dietzgen 1733 - Polymath Decimal Trig Log Log
Made in USA - 22 scales - S/N B506105
Patents: Stock: 2,170,144; 2,285,722. Cursor: 2,634,912
Front Scale
LL01, K, A [ B, T Cot, ST, S  Cos ] D, L, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, CI, C ] D, LL3, LL2
Previous owner:  Eugene Mulder, On slide: R.L.F.Z



Dietzgen 1733 Polymath Decimal Trig Log Log

ISRM 13.10.09.06
Dietzgen 1733 - Polymath Decimal Trig Log Log
Made in USA - 25 scales - S/N 005585
Patents: Stock: 2,170,144; 2,285,722. Cursor: 2,634,912
Front Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2
Previous owner. was in New Zealand
Gift of Phillip Rodley, Upper Hutt, New Zealand.



Dietzgen N1733 Polymath Multiplex
Decimal Trig Type Log Log

ISRM 11.12.16.01

Eugene Dietzgen Co. Insert Copyright 1950
Form No. 1700-SRT/500B/PN25
Dietzgen N1733 - Polymath Multiplex Decimal Trig Type Log Log
Made in USA - 25 scales - S/N 080525 - 1962
Patents: Stock: 2,170,144; 2,285,722. Cursor: 2,634,912
Front Scale (same as 1734)
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2
Original Owner: Harold John Morgan, Chesapeak Beach, Maryland. Purchased 1962, used at PSU for EE degree. Worked for FCC, retired 2004.


Dietzgen 1734 Microglide Decimal Trig Log Log

ISRM 14.10.15.01


USS Pueblo 1967, Authentication Letter, Medals Awarded
Dietzgen 1734 - Microglide Decimal Trig Log Log
Made in USA - 22 scales - S/N 114559 - c1947
Front Scale: LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale: LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2
Original Owner(s): Sergeant (USMC) Robert J. Chicca of Bonita, California. a POW of the 1968 USS Pueblo incident with North Korea.
Gift of Edward T. Wright, Odenton, Maryland.
This slide rule belonged to USMC SSGT Robert J. Chicca,shown in the ohoto, who with the rest of the crew of the USS Pueblo (AGER-2), a signal intelligence ship, were attacked, and captured by North Korean forces on 23 January 1968, One sailor was killed in the attack. Crew members had their hands tied and were blindfolded, beaten, and prodded with bayonets. Pueblo was taken into port at Wonsan and the crew was moved twice to POW camps. The crew reported upon release that they were starved and regularly tortured while in North Korean custody. This treatment allegedly turned worse when the North Koreans realized that crewmen were secretly giving them "the finger" in staged propaganda photos They were held captive for 8 months before being released across the DMZ in December, 1968. The slide rule was also used by Roberts brother, Bill in school, while Robert was in the military. See Wickipedia entry


Dietzgen 1734 Microglide Decimal Trig Log Log

ISRM 12.06.24.24

Dietzgen 1734 - Microglide Decimal Trig Log Log
Made in USA - 22 scales - S/N 056181 - c1947
Front Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2
Donated by Anonymous collector and daughter .
The collector, who prefers to remain anonymous, obtained a B.S. degree in Physics from Taiwan's National Tsing Hua University in 1971. His love for computation has encouraged him to build a collection of slide rules, HP and TI calculators, as well as abaci, many displayed at ISRM.


Dietzgen B-1734 Decimal Trig Log Log

ISRM 21.08.12.04
Dietzgen B-1734 Decimal Trig Log Log
Made in Japan by Relay/Ricoh for Dietzgen - dc SS-5 (1970)
Note: the 'B' in the model number stands for Bamboo.
Front Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2


Dietzgen G-1734 Microglide Decimal Trig Log Log

ISRM 21.08.12.05
Dietzgen G-1734 Microglide Decimal Trig Log Log
Made in Germany by Faber-Castell for Dietzgen - dc671 (June 1971)
Note: the 'G' in the model number stands for 'Geroplast' plastic.
Front Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2


Dietzgen 1735 Vector Type Log Log

ISRM 18.04.06.109
Dietzgen 1735 Vector Type Log Log
Made in USA - 23 scales - S/N 103948 - Early Frameless Cursor
Front Scale
LL0, LL00, A [ B, T Cot,  ST, S Cos  ] D, Th, Sh2, Sh1
Rear Scale
L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Gift of Leroy Hausler Collection


Dietzgen 1735 Vector Type Log Log

ISRM 14.07.02.33
Dietzgen 1735 Vector Type Log Log
Made in USA - 21 scales - sn111567 - Metal framed Cursor
Front Scale
LL0, LL00, A [ B, T Cot,  ST, S Cos  ] D, Th, Sh2, Sh1
Rear Scale
L, LL1, DF [ CF, CIF, CI, C ] D, LL3, LL2
Original Owner: W.H. Camp
Gift of Ed Millis, Dallas, Texas


Dietzgen 1737 Decimal Trig Type Log Log

ISRM 19.10.27.01
Dietzgen 1737 - Decimal Type Trig Log Log
Made in Japan by Relay/Ricoh - 22 scales Bamboo stock
Front Scale
K, A [ B, S Cos, T1 Ctg1, T2 Ctg2, C ] D, DI, L
Rear Scale
LL1, LL2, LL3, DF [ CF, CIF, CI, C ] D, LL3, LL2, LL1
Gift of the Jerome Drews Collection. Kent, Washington.

Instructions (1.02MB)


Dietzgen 1738 Multilog Multiplex Style-M (c1954)

REF S113
Dietzgen 1738 Multilog Multiplex Style M (Metal cursor bars)
Made in Germany by Ecobra, 1954 - 22 scales Improved Dec Trig Log Log; Painted Aluminum Stock,
Front Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2


Dietzgen 1738 Multiphase Style-M ©1954
Improved Decimal Trig Type Log Log Rule

ISRM 12.06.24.25
Dietzgen 1738 Multiphase Style M Improved Decimal Trig Type Log Log;
Made in Germany by Ecobra, 1954 - 24 scales, Plastic cursor bars, Painted Aluminum Stock,
Front Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2
Donated by the Huamg Collection.


Dietzgen 1738 Multiphase Style-M (c1954)
Improved Decimal Trig Type Log Log Rule

ISRM 11.12.02.01
Dietzgen 1738 Multiphase Style-M Improved Decimal Trig Type Log Log Rule
Made in Germany by Ecobra, - 24 scales Plastic cursor bars, Green slide. Painted Aluminum Stock
Front Scale
LL01, K, A [ B, T<45 Cot, T>45 Cot, ST, S Cos  ] D, DI, LL1
Rear Scale
LL02, LL03, DF [ CF, CIF, L, CI, C ] D, LL3, LL2
Original Owner: E. Nosco (Sgt) Wickcliff, Ohio, and D.A. Miller (both marked on brown leather sleeve flap)


Dietzgen 1739-L Clear-Scale

ISRM 15.05.09.05
Dietzgen 1739-L Clear-Scale
Made in Germany, 1954 - 23 scales Improved Dec Trig Log Log
Front Scale
L, K, A [ B, CI,  C  ] D, LL1, LL2, LL3
Rear Scale
T1 Cot, T2 Cot, DF [ CF, CIF, CI, C ]  D, S Cos, ST, P
Gift of Dick Rose, Rose Vintage Instruments


Dietzgen Phillips 1740

ISRM 2012.06.18.04

Dietzgen Phillips 1740
Made in Germany
Front Scale
10inch // K, A [ B, R, C ] D || 25cm
Back Scale
[ S, L, T ] Back: Equivalents
This slide rule was put on eBay by RAdm Rhoad's grandson.
This slide rule was used by Rear Admiral Forrest (Dusty) Rhoads prior to or during WWII. He later bought a Hemmi 153 in 1949 which can be seen in the Sun Hemmi Gallery.

Forrest Alexis Rhoads (1898-1965) was a career naval officer in the United States Navy and his career spanned from an Apprentice Seaman to Rear Admiral and he served in both WWI and WWII. The pictures show him in rank from apprentice Seaman (on left, 1916 on the USS South Dakota), Seaman 1st Class (on left, c1920), Captain (1947), Rear Admiral (on right, 1949) and his final promotion at the National Memorial Cemetary in Honolulu, Hawaii (1965). See an expanded biography at ancestry.com.


Dietzgen 1741 Novo Biplex

ISRM 18.09.17.25
Dietzgen 1741 Novo Biplex
Made in Germany for Dietzgen
Front Scale
K, T1 Cot, T245 Cot DF [ CF, CIF, CI, C ] D, S Cos, ST, P
Rear Scale
LL03, LL02, LL03, W2 [ W2', L, C, W1'  ] W1, LL1, LL2, LL3
Gift of Donald S. Bachelor Collection


Dietzgen 1743 Polymath Multiplex Trigonometric

REF S338
Dietzgen 1743 Polymath Multiplex Trigonometric
Made in USA - 15 scales - S/N 175663
Note: Degrees divided in 12 divisions - minutes and seconds
Front Scale
K, A [ B, T Cot, ST, S Cos ] D, DI
Rear Scale
DF [ CF, CIF, CI, C ] D, L


Dietzgen 1744 Polymath Multiplex Decimal Trig

ISRM 12.06.24.29
Dietzgen 1744 Polymath Multiplex Decimal Trig
Made in USA - 15 scales - S/N 300543
Front Scale
K, A [ B, T Cot, ST, S Cos ] D, DI
Rear Scale
DF [ CF, CIF, CI, C ] D, L
Donated by Anonymous collector and daughter .



Dietzgen 1745LM USMC Issue - Magnifying Cursor

ISRM 2011.10.28.02
Dietzgen 1745LM USMC Issue - Magnifying/Frameless Cursor
Made in USA - 11 scales - No S/N
Front Scale
K, A [ B, CI, C ] D
Rear Scale
A [ S, T ] D, L
Purchased at a Denver Antique Store in 2011


Dietzgen 1745 Mannheim - Early Frameless Cursor

ISRM 16.05.26.01
Dietzgen 1745 Mannheim - Early Frameless Cursor
Made in USA - 11 scales - No S/N
Front Scale
K, A [ B, CI, C ] D
Rear Scale
A [ S, T ] D, L
Note: One lens was missing and replaced with a fabricated plastic lens from a Ricoh slide rule cursor.


Dietzgen 1745 - Early Frameless Cursor

REF S485
Dietzgen 1745 - Early Frameless Cursor
Made in USA - 11 scales - No S/N
Front Scale
K, A [ B, CI, C ] D
Rear Scale
A [ S, T ] D, L



Dietzgen 1746 Maniphase Multiplex - Early Cursor

REF S479


Dietzgen 1746 Maniphase Multiplex - Recon. Cursor

REF S479
Dietzgen 1746 Maniphase Multiplex - Early Cursor
Made in USA - 12 scales - No S/N
Front Scale: A [ B, S, T ] D, K
Rear Scale: DF [ CF, CIF, CI, C ] D, L
Note: has same KERCS problem as early K&E's
Original Owner: Franklin James Sullivan, (1914-1992) born in Wilmington, Delaware. Cost Analyst at Baldwin's outside of Philadelphia, PA(1940-1945), then at Atlas Powder Company (Du Pont)/ICI. Had 3 daughters, one provided this slide rule.



Dietzgen 1746 Maniphase Multiplex - 1926 Early Cursor

ISRM 13.05.04.01


Mines Award

Dietzgen 1746 Original Cursor (1926)
The slide rule as above has a restored cursor, to replace the crumbling original shown on left. The early lens and metal lens brackets were retained, a SIC (Relay) cursor spacers were modified, drilled and tapped with 1-72 UNF threads, to accept new screws (K&E uses 1-72's). This gives this 'old soldier' a new life.
Dietzgen 1746 Maniphase Multiplex - Early Cursor - sn702167
Made in USA - 12 scales
Front Scale: A [ B, S, T ] D, K
Rear Scale: DF [ CF, CIF, CI, C ] D, L
Note: had same KERCS problem as early K&E's
Gift of Barbara Emmett of Dallas, TX, daughter of W.P. Morris.

Original Owner: William Page Morris. He used this slide rule while attending the Colorado School of Mines and later in his career. The following biography was written in 1969 when he received The American Institute of Mining, Metallurgical, and Petroleum Engineers (AIME) AIME Charles F. Rand Memorial Gold Medal: "William Page Morris was president and a director of the Duval Corporation of Houston, Texas. During his 38-year career in mining, he has given unselfishly of his time and talents to numerous associations. Mr. Morris received his degree in mining engineering from the Colorado School of Mines in 1930. He began his mining career a year later with Valier Coal Company in Valier, Illinois. In 1932 he joined United States Potash Company in Carlsbad, N. M. and stayed until 1940, worked first as an underground motorman and later (1934-1940) as a safety and haulage engineer. In 1940 Morris went to work for International Minerals & Chemical Corporation in Carlsbad and stayed on until 1949 when he joined Duval Corporation as general superintendent. At Duval he was named vice president and assistant general manager in 1954, executive vice president in March, 1957, and president in June, 1957. In October of 1967 he was appointed president and a director of Duval Sierrita Corporation and in September of 1968 president and a director of Duval Corporation of Canada. He is also a director of Duval Sales Corporation. Mr. Morris is a director of The Sulphur Institute, the American Potash Institute, Inc., and the New Mexico Mining Association. He was the 1962 recipient of the Distinguished Achievement Award of the Colorado School of Mines."



Dietzgen 1746 Maniphase Multiplex

ISRM 13.07.03.19

Dietzgen 1746 Maniphase Multiplex
Made in USA - 14 scales - sn703397
Note: Early scale set, improved cursor. Laminated mahogany stock, edges exposed
Front Scale
A [ B, T, ST, S ] D, K
Rear Scale
DF [ CF, CIF, CI, C ] D, L
Gifted by Daniel Swerdlow of Bethesda, Maryland
Daniel Swerdlow is a second-generation engineer from New York City and has degrees in electrical engineering from New York University and Michigan State University. He has done telecommunications engineering for major corporations and currently lives in the Washington, DC area and works at the United States Patent and Trademark Office. Dan has gifted most of his collection to ISRM to support the museum. Many specimens may be found in the various ISRM galleries.


Dietzgen 1749 Style-M Dec Trig Maniphase

REF S355
Dietzgen 1749 Style-M Dec Trig Maniphase
Made in Germany - 1959 - 15 scales
Metal stock, powder coated, silkscreened scales
Front Scale
K, A [ B, T, ST, S ] D, DI
Rear Scale
DF [ CF, CIF, CI, C ] D, L


Dietzgen 1750P Maniphase

REF S562
S364 Dietzgen 1750P Maniphase
Made in USA - pre1938 - 9 scales
Front Scale
10in // E/K, A [ B, R/CI, C ] D || 25cm
Rear Scale
[ S, L, T ]

This was a manufacturing transition that re-labeled both E as K and R as CI. The later was an error in implementation as R = 1/A, (100-10-1, the Phillips scale) and CI =1/C (10-1). The divisions on the center scale of the slide are for the CI or Reciprocal scale of C.


Dietzgen 1750P Maniphase

REF S364
Dietzgen 1750P Maniphase
Made in USA - 1938 - 9 scales
Front Scale
10in // K, A [ B, CI, C ] D || 25cm
Rear Scale
[ S, L, T ]


Dietzgen 1751 - Industrial Slide Rule

REF
Dietzgen 1751 - Industrial Slide Rule
Made in USA
Front Scale
Feed, Length of Cut [ RPM, Time, Cutting Speed ] D
Rear Scale
L, A [ B, CI, C ] D, K
Scan provided by Jim Cerny, New Castle, New Hampshire
1950 Catalog Description


Dietzgen 1755L Mannheim 5"

REF P259
Dietzgen 1755L Mannheim 5"
Made in USA - 1938 - 7 scales
Front Scale
5in // A [ B, C ] D || 12.5cm
Rear Scale
[ S, L, T ]
Note: Early Dietzgen slide rules has a model number suffix of 'P' to deonte a 'Plain' cardboard case. A suffix of 'L' is used for a sewed 'Leather' case.


Dietzgen 1757 Primatrig

REF S442
Dietzgen 1757 Primatrig
Made in USA by Acu-Rule for Dietzgen - All Plastic Stock/slide, metal ends. Similar to (S427) Acu-Math 600 Basic Trig
Front Scale
L, K, A [ B, CI, C ] D, T Cot, ST, S Cos
Rear Scale
Trig Identities [ Decimal to Fractions ] Equivalents

Same as S427 Acu-Math 600 Basic Trig (scales rearranged)


Dietzgen 1757 Primatrig

ISRM 12.05.06.02
Dietzgen 1757 Primatrig
Made in USA by Acu-Rule for Dietzgen - All Plastic Stock/slide/ends
Front Scale
L, K, A [ B, CI, C ] D, T Cot, ST, S Cos
Rear Scale
Trig Identities [ Decimal to Fractions ] Equivalents
Donated By Scott Reynolds, (Vintage Calculators, Inc), Helmut, California


Dietzgen Phillips 1759 1914-1915

ISRM 13.10.25.01
Dietzgen Phillips 1759 1914-1915
Made in USA
Front Scale
10inch //  A [ B, R, C ] D || E
Back Slider
[ S, L, T ] Back: Equivalents
Cursor: hairline stamped in metal on the side scale 'E'
Original Owner: Hoey, who marked the University class he was in as '15, in the well.
Note: This slide rule was used during the start of WWI. More officers were given General's stars from this 1915 class by WWII, than any other year. It is probable that Hoey survived the war, as his slide rule survived to be sold by his family on ebay in 2013, almost 100 years later.


Dietzgen Phillips 1759B 1914-1915

ISRM 16.05.10.02

Clifford, Sr. studied chemical engineering at Carnegie Tech in the 1920's and later mechanical engineering at the University of Buffalo. He served in the Army as a Major in the Chemical Warfare Service at Edgewood Arsenal during WWII. During the Korean War, he served as the Commanding Officer of the Engineering Agency at the Army Chemical Center at Edgewood and was promoted to Brigadier General. His career in industry included serving as the Director of Central Engineering at FMC.
Dietzgen Phillips 1759B 1914-1915
Made in USA
Front Scale
10inch // A [ B, R, C ] D || E(K)
Back Slider
[ S, L, T ] Back: Equivalents
Well: Blank Mahagony
Cursor: (Restored) hairline stamped in metal on the side scale 'E'
Original Owner: Clifford L. Sayre (Sr). C.L. Sayre, marked on back.
Sleeve marked: Clifford L. Sayre Carnegie Institute of Technologies, Chemical Engineering 192?.
Donated by Marie Sayre Cole of Wappingers Falls, NY, Daughter of C.L. Sayre Jr. His slide rules are also in the galleries. See K&E 4080-3 and Gerber GA-103.



Dietzgen Phillips 1759B with Magnifier c1914

ISRM 21.04.07.03

Dietzgen Phillips 1759B with Magnifier 1914-1915
Made in USA by Eugene Dietzgen Company.
Front Scale: 10inch // A [ B, R, C ] D || E(K)
Back Scale: [ S, L, T ] Back: Equivalents
Well: Blank Mahagony
Cursor: Magnifying with hairline molded on the side scale 'E'
Belonged to George Washington Champe, Engineer, (1868-1937)
Gift Of Katherine Champe Jones of Vienna, Virginia. (Granddaughter).
Geoerge W. Champe was born in Dublin, Indiana, and was an 1893 graduate of of the University of Indiana. Soon after graduation he became the Bloomington, Indiana City Engineer. He spent one year at the Rose Polytechnic Institute and in 1900 opened his Toledo office for private engineering practice. His arrival in Toledo coincided with a boom in the development of interurban electric railroads and he became a specialist in that field. In those years he devoted much time in pavement design and construction. He was a part time instructor in the University of Toledo engineering college,, vice chairman of the Toledo City Plan commission, chairman of the Lucas county planning commmision, and assisted the city civil service commision in the examination of applicants for engineering positions. See more at in the K&E Specialty Gallery for the Nordell Sewer Rule.


Dietzgen 1760A c1925
ISRM 20.04.01.423
Dietzgen 1760A c1925
Made by Eugene Dietzgen Company.
Front Scale
5in // A [ B, C ] D || E(K)
Back Scale: [ S, L, T ]
Back: Equivalents. Promo engraved in gold: The Van Sciver Corporation
Gift of the Philip E. Stanley Collection.
1925 Catalog The Van Sciver Corporation, originally, J.B. Van Sciver Furniture Co.. was a furniture company in Camden, New Jersey, founded in 1881 by Joseph Bishop Van Sciver and later run by his sons, Joseph Bishop Van Sciver Jr., Lloyd Van Sciver, and Russell Van Sciver. The company also opened stores in Allentown, Pennsylvania and Trenton, New Jersey.


Dietzgen 1760 10inch Mannheim c1928

ISRM 21.09.18.02
Dietzgen Multiplex 1760 10inch Mannheim c1928
Made in USA
Note: Degrees divided in 10 divisions - decimal
Front Scale: 10inch // A [ B, C ] D || 25cm
Back Scale: [ S, L, T ]
Back: Equivalents


Dietzgen Multiplex 1760B

REF S213
Dietzgen Multiplex 1760B - Closed Simplex
Made in USA
Note: Degrees divided in 10 divisions - decimal
Front Scale: 10inch // A [ B, C ] D || E
Back Scale: [ S, L, T ]
Back: Equivalents


Dietzgen 1760P Mannheim All Glass Cursor

ISRM 13.10.25.01
Dietzgen 1760P Mannheim - Closed Simplex
Made in USA - Note the "P" in the 1760 is printed on the case flap end
Note: Degrees divided in 12 divisions - minutes and seconds
Front Scale: 10inch // A [ B, C ] D || 25cm
Back Slide: [ S, L, T ] Back: Equivalents
Note: the All Glass Cursor, Patent US 1855523, is being shared with the 1762 20" version, ISRM 13.10.10.01
Case Archive Image


Dietzgen 1761AL 1927

REF

Dietzgen 1761AL 1910-1912
Made in USA
Front Scale: 10inch // A [ BI-1-B, C ] D || E(K)
Back Slider: [ S, L, T ]
Back: Equivalents
Well: Blank Mahagony
Cursor: (Restored) hairline stamped in metal on the side scale 'E'
Original Owner: Charles A. Kroft (Marked on back of stock and sleeve, labeled 1762AL).
Sleeve marked:Chassis Engineering, Studebaker Corp. So. Bend, Indiana.
Scan donated by Michael Sypher Collection.
This slide rule belonged to Charles A. Kroft who worked at the Studebaker factory from 1927 until it closed in 1963.


Dietzgen 1762B sn3746A - Patent June 28, 1898

REF S473
Dietzgen 1762B sn3746A - Patent June 28, 1898
Made in USA by Eugene Dietzgen Co.
Patent Markings: June 28, 1898, Patent Aug 9, 1904
Note: Combination BI-1-B scale, Index in center of scale
Front Scale: 10inch // A [ BI-1-B, C ] D || LL
Back Slide: [ S, L, T ]
Back: Equivalents
Original Owner: R.C.L. Greer


Dietzgen 1763-AL Mannheim sn7625A

REF
Dietzgen 1763-AL Mannheim sn7625A
Made in USA by Eugene Dietzgen Co.
Patent Markings: June 28, 1898, Patent Aug 9, 1904
Note: Combination BI-1-B scale, Index in center of scale
Front Scale: 8inch // A [ BI-1-B, C ] D || 20cm
Back Slide: [ S, L, T ]
Back: Equivalents
Archive - Scans provided by Cassou Olivier Collection, France


Dietzgen 1765F c1925 (Unis France)
ISRM 20.04.01.013
Dietzgen 1765F c1925 (Unis France)
Made in France by Unis MARC for Eugene Dietzgen
Same as Guedon - See Misc USA
Front Scale
5in // A [ B, C ] D
Back Scale: 13cm [ Blank ]
Gift of the Philip E. Stanley Collection.

From Catalog page in 1925 Manual


Dietzgen 1765W Handy c1940
ISRM 20.04.01.266
Dietzgen 1765W Handy c1940
Made in USA by Roos for Eugene Dietzgen
Note: same stock width and cursor as early 1767P or 1768P
Front Scale: A [ B, C ] D, K
[ S, L, T ]
Back and Well: Conversion Charts
Gift of the Philip E. Stanley Collection.


Dietzgen 1765P Basik

ISRM 09.01.12.121
Dietzgen 1765P Basik
Made in Germany
Front Scale
10in // K, A [ B, CI, C ] D, L
Back Scale
[ S, ST, T ]
Back: Conversion Chart
Donated by David Hecht, Alexandria, VA


Dietzgen 1765P Basik

ISRM 19.10.27.02
Dietzgen 1765P Basik dc 1265 (Dec 1965)
Made in Germany
Front Scale
10in // K, A [ B, CI, C ] D, L
Back Scale
[ S, ST, T ]
Back: Conversion Chart
Gift of the Jerome Drews Collection of Kent, Washington.




Dietzgen 1766P

REF S110
Dietzgen 1766P - Closed  Simplex -
Made in Germany - Ca 1933
Front Scale
A [ B, C ] D
Back Slider
[ S, L, T ] Back: Conversion Chart


Dietzgen 1767P National - Early Cursor

ISRM 18.09.17.34
Dietzgen 1767P National - Early Cursor
Made in USA
Note: early Cursor, Paper back label
Front Scale
A [ B, CI, C ] D, K
Back Scale
10in [ S, L, T ] 25cm, Conversion Chart (label)
Gift Of Donald Bachelor Collection.


Dietzgen 1767P National

REF S394
Dietzgen 1767P National - c1942
Made in USA - Same as Post 1446-D
Front Scale
A [ B, CI, C ] D, K
Back Scale: [ S, L, T ]
Back: Early Conversion Chart (label)


Dietzgen 1767P National

ISRM 14.09.21.07

Dietzgen 1767P National
Made in USA, possibly by Charvoz-Roos or Festus later acu-math)
Front Scale
A [ B, CI, C ] D, K
Back Slider
[ S, L, T ] Back: Conversion Chart
Gift Of Edward Wright of Odenton, Maryland.


Dietzgen 1767 National

ISRM 13.06.28.02


Dietzgen 1767 National - c1966
Made in USA by Acu-math - Note cursor fits in groove on edge of stock
Front Scale
K, S, A [ B, CI, C ] D, T, L
Back Blank
Note: This basic mannheim type slide rule was supplied to U.S Navy students attending the Nuclear Warfare School at the Nuclear Weapons Training Center - Atlantic, in the 60's and 70's. A student had to be nominated by their command to a attend this school. One of the course books Review of Mathematics and Slide Rule is on the left.
Gift Of Susan Jackson, Boulder, Colorado, daughter of Jim Rodgers

Jim Rodgers (1929-2012) used this slide rule (and others found within ISRM) during his career. He was a Naval Aviator and had training at the the Nuclear Weapons Training Center - Atlantic (c1968). He later resided in Boulder, Colorado. He was married to Ceil Rodgers for 63 years and had four children, Jim, Susan, Cathy and Stephen, and eight grandchildren. An avid reader, progressive thinker, political junkie, problem solver and perpetual optimist, Jim was loved and admired by everyone who knew him. Jim donated his body to science.


Dietzgen 1767 National

REF S258
Dietzgen 1767 National - c1966
Made in USA by Acu-math - Note cursor wraps around width of stock
Front Scale
K, S, A [ B, CI, C ] D, T, L
Back Blank
Orig Owner: Carol Tideman
Last owner: Patricia Turner, Boulder, CO


Dietzgen 1767 National

ISRM 11.03.23.02
Dietzgen 1767 National - c1966
Made in USA by Acu-math - Note cursor wraps around width of stock
Front Scale
K, S, A [ B, CI, C ] D, T, L
Back Blank
Donated by David Sweetman
Instructions (10.3MB PDF) Gift Of Phillip Rodley


Dietzgen 1768 Mannheim 1922

ISRM 21.08.12.06
Dietzgen 1768 Mannheim 1922
Made in USA c1922 (appears in 1922 price list)
Note: This 1768 model number was later reissued during WWII on the 1768P Reliance model.
Front Scale: 5in // A [ B, C ] D, K || 12.5cm
Back Scale: [ S, L, T ]
Back: Equivalents (English)


Dietzgen 1768P Reliance

REF
Dietzgen 1768P Reliance (eBay)
Note: Metal Framed Cursor
Made in USA c.1940
Front Scale: A [ B, CI, C ] D, K
Back Scale: 10inch [ S, L, T ] 25cm
Back: Equivalents


Dietzgen 1768P Reliance

REF S371
Dietzgen 1768P Reliance - Closed Simplex
Note: Thin Film plastic Cursor
Made in USA c.1940
Front Scale: A [ B, CI, C ] D, K
Back Scale: 10inch [ S, L, T ] 25cm
Back: Equivalents



Dietzgen 1768P Reliance

ISRM 21.08.07.31
Dietzgen 1768P Reliance - Closed Simplex
Note: Molded plastic Cursor
Made in USA c.1942
Front Scale: A [ B, CI, C ] D, K
Back Scale: 10inch [ S, L, T ] 25cm
Back: Equivalents



Dietzgen 1768-P

REF S402
Dietzgen 1768-P - Open Simplex
Made in Japan (by Fuji?) for Dietzgen, c1970
Front Scale
K, S, A [ B, CI, C ] D, T, L
Back: Blank
Purchased out of Lima., Peru
Note: braces on back side of stators.


Dietzgen 1768-P Maniphase

REF S493
Dietzgen 1768-P Maniphase -Open Simplex
Made in Japan (by Fuji?) for Dietzgen, c1970
Front Scale
K, S, A [ B, CI, C ] D, T, L
Back: Blank
In Unopened Retail Bag, Note braces on scale side of stators.



Dietzgen 1769

REF S501
Dietzgen 1769 - pre WWIII
Made in USA
Front Scale
10inch // A [ B, C ] D, K || 25cm
Back Scale
[ S, L, T ] Back: Equivalents



Dietzgen 1769P Federal

REF S257
Dietzgen 1769P Federal - cWWII
Made in USA
Front Scale
10inch || A [ B, CI, C ] D, K || 25cm
Back Scale
[ S, L, T ] Back: Equivalents
Original Owner: Unk


Dietzgen [Redi-rule] Version 1

REF P058
Dietzgen [Redi-rule] Thin Film Cursor
Made in USA by Bruning
Front Scale
K, A [ B, CI, C ] D
Back Slide: [S, ST, T ]
Back 5in, 12.5mm


Dietzgen (1771) Redirule - narrow plastic Cursor

REF P197
Dietzgen (1771) Redirule - narrow plastic Cursor
Made in USA by Bruning
Front Scale
5in // K, A [ B, CI, C ] D \\ 12.5cm
Back Scale: [S, L, T ]
Back: Blank



Dietzgen (1771) Redirule - Narrow metal cursor

ISRM 20.04.01.121

.
Dietzgen (1771) Redirule - Narrow metal cursor
Made in USA by Bruning - 9 scales
Front Scale: 5 inch // A [ B, CI, C ] D, K \\ 12.5 cm
Rear Slider: [S, L, T
Gift of Philip E. Stanley


Dietzgen (1771) Redirule - Wide metal cursor

ISRM 21.05.29.02
Dietzgen (1771) Redirule - Wide metal cursor
Made in USA by Bruning, same as 2401
Front Scale: 5in // K, A [ B, CI, C ] D \\ 12.5cm
Back Scale: [S, L, T ]
Original owner: Robert G. Goody, 1915-2000
Gift of Nancy H. Goody (daughter) of Albany, New York Belonged to father.
Robert G. Goody (1915-2001) was a Professional Electrical Engineer and became the Chief Engineer for Federal Pacific Electric in Newark, New Jersey from the 1950s through the 70's. He was listed in the Men of Science Who's Who. His Amateur radio call sign was WB2MZL.

43MB PDF
Dietzgen 1771 Redirule - Screwed Cursor
ISRM 17.10.10.02

.
Dietzgen 1771 Redirule - Screwed Cursor
Made in USA - 9 scales
Front Scale: 5 inch // A [ B, CI, C ] D, K \\ 12.5 cm
Rear Slider: [S, L, T
Back Adv: Arthur G. McKee & Company, Engineers & Constructors, Cleveland, Ohio
Original Owner/Location: Brian C. Cunningham, Australia (has name on back of stock)
Donated by Andrew (son) and Barbara (wife) Cunningham, Willagee, W.A., Australia.

Brian C. Cunningham (1935-2013)
Brian was born in Port Pine, South Australia, Australia. His education commenced there and continued at the South Australian School of Mines where he gained his Diploma in Mining & Metallurgy. He became a Student Member of the Australian Institute of Mining & Metallurgy rising to a Fellow member. Brian started his career as a Metallurgical Cadet at the B.H.A.S. (Broken Hill Associated Smelters) in Port Pirie. He transferred to Hamersley Iron in Perth, Western Australia, the subsidiary company of Conzinc Rio Tinto Aus. where he became an Executive Officer of the Hamersley Iron Group. In Brian's studies and work his slide rules where used extensively.


Dietzgen 1772A

ISRM 09.01.12.122
Dietzgen 1772 A
Made in USA by Acu-Rule/Sterling- 10 scales
Front Scale: K, A [ B, CI, C ] D, L
Back: Blank
Original Owner: H.W.F. (Initials on sleeve)
Donated by David Hecht, Alexandria, VA.


Dietzgen 1772B Union Slide Rule - Mannheim

REF
Dietzgen 1772B Union Slide Rule - Mannheim
Made in USA - c1930
Front Scale: A [ B, C ] D
Rear Scale: [ S, L, T ]
Archive - Contributed by Jan Pratt


Dietzgen 1773 System Darmstadt

ISRM 20.04.01.094
Dietzgen 1773 System Darmstadt- Date code 861 (Aug 1961)
Made in Germany for Dietzgen by Faber-Castell - 14 scales
Same as Faber-Castell 67/54 B Darmstadt
Front Scale (extended)
5in // L, K, A [ B, CI, C ] D, P, S, T
Back Scale 14cm [ LL1, LL2, LL3 ]
Gift of the Philip E. Stanley Collection.


Dietzgen 1774-M Maniphase - postWWII
ISRM 20.04.01.376
Dietzgen 1774-M Maniphase - post WWII
Made in Germany (U.S. Zone) for Dietzgen by Ecobra - all Aluminum
Note: Missing cursor.
Front Scale (extended): 5in // K, A [ B, CI, C ] D, L
Back Scale: [ S, T ]
Back and Well: Conversion Charts
Gift of the Philip E. Stanley Collection.


Dietzgen 1774-M Maniphase

REF P221
Dietzgen 1774-M Maniphase - post WWII
Made in Germany (U.S. Zone) for Dietzgen by Ecobra - all Aluminum
Front Scale (extended)
5in // K, A [ B, CI, C ] D, L
Back Scale: [ S, T ]




Dietzgen 1776 Redirule Pocket Duplex

ISRM 14.07.02.84
Dietzgen 1776 Redirule Pocket Duplex
Made in USA - 15 scales
Front Scale
K, A [ B, T, ST, S ] D, DI
Rear Scale
DF [ CF, CIF, CI, C ] D, L
Gift of Ed Millis Collection, Dallas, Texas.


Dietzgen 1776 Redirule 5" Pocket (Duplex)

ISRM 13.07.03.12

Instructions 10.9MB
Dietzgen 1776 - 5" Redirule Pocket Duplex
Made in USA - 15 scales - Complete in Box
Front Scale
K, A [ B, T, ST, S ] D, DI
Rear Scale
DF [ CF, CIF, CI, C ] D, L
Promotional Marking: KOPPERS
Gift of Dan Swerdlow, Bethesda, Maryland.


Dietzgen 1776 redirule

ISRM 09.01.12.128
Dietzgen 1776 - 5" Redirule
Made in USA - 15 scales
Front Scale
K, A [ B, T, ST, S ] D, DI
Rear Scale
DF [ CF, CIF, CI, C ] D, L
ADV: Electronic Specialty Co.
Donated by David Hecht, Alexandria, VA


REF Dietzgen 1777 (ECOBRA)
Dietzgen 1777
Made in Germany, U.S. Zone - All Metal
Front Scale
K, A [ B, R, C ] D, L(Lg)
Rear Scale
12cm [ Sin, Tg ] 5in
Scan donated by Olivier Cassou, France
Case Marked "Germany, U.S. Zone"


Dietzgen 1778 Pocket MultiLog

ISRM 20.04.01.232
Dietzgen 1778 - Pocket MultiLog (1969)
Made in Germany - 24 scales, dc869 (Aug 1969)
Front Scale: L, Ti, T2 A [ B, BI, CI, C ] D, ST, S Cos, P
Rear Scale: LL03, LL02, LL01, K [ K', C, CIF, CF ] DF, LL1, LL2, LL3
Cursor: Multi-lined
Gift of Philip E. Stanley Collection.



Dietzgen 1779 PocketLog

ISRM 20.04.01.199
Dietzgen 1779 - PocketLog
Made in Germany U.S. Zone by Ecobra - 17 scales, aluminum stock
Front Scale
K, A [ B, Lg, C ] LL3, LL2, LL1
Rear Scale
Sin Cos, Tg Ctg, DF [ CF, CI, C ] D, P
Cursor: Multi-lined, D, Q, W, HP


Dietzgen 1797A (Gilson Atlas) Type-3 21.1cm dia

REF
Dietzgen 1797A (Gilson Atlas) Type-3 21.1cm dia.
Made in USA by Gilson
Front Scales
C, S-Log, C (25 spirals), C-Log, Coils, Constants
Back Scales
Degrees, S, T, Degrees, S, T, Degrees, S, T, Fractions
Archive - No longer in collection
4.08MB


Dietzgen 1797B (Gilson Binary) 21.1cm dia

ISRM 17.07.27.02


Archive photos of Retail box.
Dietzgen 1797B (Gilson Binary) 21.1cm dia.
Made in USA by Gilson for Dietzgen
Front Scales
C,CI,A,K,Log,LL1,LL2,LL3,LL4,Binary, Fraction,Drill,Thread, Millimeter
Back Scales
Degrees, S, T, Degrees, S, T, Degrees, S, T, Fractions
Gift of Linda N. Boclair, Voohees, New Jersey. Belonged to Spafford W. Schanck.

Original owner: Spafford W. Schanck.(1899-1985)used the slide rule during his career as a business owner and building contractor in Washington DC and later in the Matawan, New Jersey area where he owned and operated the Matawan Lumber Company and built the First Presbyterian Church. He served as Mayor for the borough of Matawan for just over seven years between 1951 and 1959. He was well liked and known for treating everyone with respect.
His stepdaughter, Linda (Newman) Boclair writes, " A little known yet interesting piece of history published in the local newspaper (Asbury Park Press) in 1952 was when Spafford defended women's rights to wear shorts in town as long as they were "decent". At the time the police were citing women seen in shorts in public. There was a reference in the article stating that wearing shorts was a sign of patriotism during World War I when there was a shortage of fabric. My step father may have used this fact to support his position."
Spafford retired with his wife Katherine to their 500-acre dairy farm in Virginia and later moved to New Jersey to be closer to his children. Katherine died in 2004.
Instructions (3.4MB PDF)


Dietzgen 1797M (Gilson Midget 1931, 1936) V1

ISRM 11.05.16.01
Dietzgen 1797M (Gilson Midget 1931, 1936) - 10.2cm dia
Made in USA for Dietzgen by Gilson Slide Rule Co., Stuart, Florida
Front Scales
C,CI,A,K,Log,LL1,LL2,LL3,LL4,
Back Scales
Binary, Fraction,Drill,Thread, Millimeter
Note: This is in the Circular gallery and used here as it matches the Dietzgen OEM



Dietzgen 1797M (Gilson Midget) V2
ISRM 08.04.10.01

Dietzgen 1797M (Gilson Midget)- 10.2cm dia
Made in USA for Dietzgen by Gilson Slide Rule Co., Stuart, Florida
Note: Copyright date removed from the previous artwork (circa 1960-70) and the background is a darker green.
Front Scales
C,CI,A,K,Log,LL1,LL2,LL3,LL4,
Back Scales
Binary, Fraction,Drill,Thread, Millimeter
Donated by Bruce Chelf of Porter, Indiana
3.72MB PDF


Dietzgen 1798 - Dempster RotaRule - model AA

REF
Dietzgen 1798 - Dempster RotaRule - Model AA (1933-1948)
Made in USA - Designed and manufactured by Jack Dempster, Berkeley, California.
Front Scales: K A D ( C CI CIF S CS ST T CT G B F/i )
Back Scales: 1-100 in 4circles DLL V2 ( V1 1-100 in 4circles LL3 LL2 LL1 LL% L )
Archive - Hermann's SR Catalog
Model 1798 shown in 1938 Dietzgen Catalog (in ISRM Library)

Eugene Dietzgen Co. History - 1885-2002

Eugene Dietzgen was born in Uckerrath, Germany on May 6, 1862, he died in Chicago on December 1, 1929. Eugene was the eldest son of Joseph Dietzgen, a German tanner-turned-Communist who read Marx and joined the Revolution of 1848, which got him exiled from Germany. At age two Eugene was taken by his father to Tsarist Russia, where he was educated in the Russian language and in his father's trade, tannery. They both returned to Germany in 1868.

In 1881, Eugene's father sent him to America to escape the Kaiser's military draft and to hide some of his father's socialist literature; the literature had already landed Joseph in jail a few years before. Eugene was only 19 years old when he arrived in New York City. He began work with a German drafting company, and eventually moved to Chicago.

In Chicago Dietzgen started the Eugene Dietzgen Drafting Company, the company was founded on November 13, 1885 under the name of Luhring & Dietzgen. This partnership was succeeded by Eugene Deitzgen & Co. in 1891. Successor corporation under the name of Eugene Dietzgen Co. of Illinois occurred on February 3, 1893 and the present corporate company, Eugene Dietzgen Co. of Delaware was incorporated in Delaware on October 29, 1917. By 1906, Dietzgen had two manufacturing plants.

The company was noted for its production of slide rules, which Dietzgen started in 1898 after acquiring a patent from John Givan Davis Mack (1867-1924). His company's Mack Improved Mannheim Simplex Slide Rule sold from 1902 to 1912 for $4.50.

Dietzgen was heavily influenced by his father, one of Karl Marx's favorite philosophers. He provided his factory workers with many amenities not often found in the 19th century. These included separate bathrooms for men and women, open windowsills with flowers decorating the air, and a general atmosphere of a healthy working community. Dietzgen 's first wife could not bear him children; they divorced, and in 1912 Eugene moved to Zurich, Switzerland. There he met his second wife, Jansen, and they had three boys and three girls.

The company still exists, and its second building remains as a part of DePaul University, at the corner of Fullerton Avenue and Sheffield, in Chicago's once heavily German neighborhood of Lincoln Park. The original building still stands at 218 East 23rd Street, Chicago, operates today as Dietzgen Corporation, a privately held company. Ref: compleatsurveyor.com

Chronology of the Dietzgen company.

  • 1885 - German immigrant Eugene Dietzgen founds his own engineering supply house as both a dealership and manufacturers' representative in Chicago, Illinois.
  • 1893 - First manufacturing facility opened producing T-squares, drawing boards, surveying instruments and other engineering supplies that are now highly valued by collectors for their craftsmanship and quality
  • 1906 - Second manufacturing facility opened at Fullerton and Sheffield Sts. In Chicago. This plant was continually expanded until sold in 1976. It is now a historical landmark.
  • 1920 - Dietzgen becomes the exclusive U.S. marketer of German dry "diazo" positive-reproduction white printer papers.
  • 1959 - Dietzgen becomes first company to market commercially viable polyester drafting films.
  • 1974-1976 - Regional coating plants are combined with distribution centers to better service primary marketing regions at competitive cost.
  • 1986 - Large document copier media - Dietzgen's first digital printing products - is introduced.
  • 1995- In its 110th anniversary year, Dietzgen announced the acquisition of the Klingler company. The newly consolidated corporation enhances both firms' contributions to the marketplace by providing new technologies, new products and new services to the reprographics industry.
  • 2002 - Nashua Corporation purchases Dietzgen assets and integrates them with its own growing digital imaging business. Retaining the Dietzgen name, this new division brings a new customer focus and paper converting expertise to the business.
  • 2004 - Nashua acquires the Magellan line of media to position Dietzgen as a full-service provider to the growing large-format graphics market.
  • 2005-2006 - Dietzgen opens new facilities in Jefferson City, TN and Cranberry, NJ, while upgrading its current plant in Los Angeles, CA, to provide better service to a customer base that has grown to more than 1,500 dealers and service bureaus.

Copyright © 2003-2021 International Slide Rule Museum
